Description
| Video / Audio input | |
| Video compression | H.264 |
| HD-TVI video input | 8ch |
| Video input interface | BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adapive |
| IP input | 2ch([email protected]) |
| Audio compression | G.711A |
| Audio input | 1-ch, RCA(2.0 Vp-p, 1 kΩ) |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Video / Audio output | |
| HDMI / VGA output | 1920 x 1080,1280 x 1024, 1280 x 720, 1024 x 768/60 Hz |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Encoding resolution | Main stream: 1080P(non-real-time) / 720P / WD1 / 4CIF Sub-stream: CIF / QCIF |
| Frame rate | Main stream: 1fps ~ Real time frame rate Sub-stream: 1fps ~ Real time frame rate |
| Video bit rate | 1280 Kbps-7168 Mbps |
| Audio output | 1-ch, RCA (Linear, 1 kΩ) |
| Audio bit rate | 64 Kbp |
| Dual-stream | Support |
| Stream type | Video, Video & Audio |
| Synchronous playback | 8-ch |
| Playback resolution | 1080P / 720P / WD1 / 4CIF / CIF / QCIF |
| Network | |
| Remote connections | 10 |
| Network protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS |
| Hard disk | |
| SATA | 1 SATA interfaces |
| Capacity | Up to 4TB capacity for each disk |
| External interface | |
| Network interface | 10M / 100M /1000M |
| Serial interface | 1; standard RS-485 serial interface, half-duplex |
| USB port | 2 × USB2.0 |
| Alarm in/out | 8/4 |
| General | |
| Power supply | DC 12V |
| Consumption | ≤ 10 W |
| Working temperature | -0 °C ~ +55 °C(32°F – 131°F) |
| Working humidity | 10% ~ 90% |
| Dimension | 12.6 × 9.6 × 2.0″ 320 ×245 × 50mm |
| Weight (without hard disk) | ≤ 3.3 lb (1.5Kg) |
